Neoflon? PFA AP-210
Introduction
AP-210 is a copolymer of tetrafluoroethylene and perfluoroalkyl vinyl ether.
Good melt flowability while maintaining excellent properties of PTFE. It can be melt-molded as a thermoplastic resin by injection molding and extrusion molding.
Excellent chemical resistance which is not affected by most of the chemicals.
Excellent heat resistance. Continuous use temperature is 260°C.
It retains flexibility without losing toughness under the environment from cryogenic to high temperature.
Low dielectric constant and dielectric loss tangent in a wide range of temperature and frequency.
It shows high electrical resistance and dielectric strength.
Nonflammable like POLYFLON PTFE and NEOFLON FEP.
Excellent weather resistance. No properties change even when exposed outside for a long time.
Non-stickiness. It shows excellent releasability and water repellency / oil repellency.
總覽 | |
材料狀態 |
|
資料 1 |
|
搜索 UL 黃卡 |
|
供應商 | 東莞市展陽高分子材料有限公司 |
特性 | 共聚物良好的柔韌性流動性高耐候性,良好耐化學品性能,良好耐熱性,高韌性良好 |
加工方法 | 擠出注射成型 |
物理性能 | 額定值 | 單位制 | 測試方法 |
密度 / 比重 | 2.14 | g/cm3 | ASTM D792 |
熔流率(熔體流動速率) (372°C/5.0 kg) | 14 | g/10 min | ASTM D3307 |
機械性能 | 額定值 | 單位制 | 測試方法 |
抗張強度 | 31.0 | MPa | ASTM D1708 |
伸長率 (斷裂) | 420 | % | ASTM D1708 |
熱性能 | 額定值 | 單位制 | 測試方法 |
連續使用溫度 | 260 | °C | |
熔融溫度 | 306 | °C | DSC |
